Speedhut EV Dual Gauge | Amp -200 to 1200A / Battery Temp

EV CAN-Bus Dual Gauge (Amps -200 to 1200A & Battery Temp) reads current draw and battery temperature directly through the CAN network at 500K baud for stable real-time monitoring of power consumption and thermal conditions. Built for clean EV integration, it delivers accurate dual-function data with a clean factory-style look to help track amperage, monitor battery temperature, and give you better insight into overall system load and battery health. A precision stepper motor keeps the pointer smooth, accurate, and easy to read at a glance, while an integrated warning light adds a clear visual alert when battery temperature rises above 104°F (40°C). Built for long-term reliability, it keeps critical EV data visible in one compact gauge, is made in the USA, and is backed for life.

Default programming is for Orion, Zero EV, and Thunderstruck systems, and a baud rate of 500 kbps. Default amperage range is -200 to 1200 A. Please contact us if you require alternate programming or a different range.

Key Features:

• Direct CAN Amps + Battery Temp Data — reads current draw and battery temperature directly from the CAN network
• 500K Baud CAN Communication — built for proper integration with supported EV systems
• Dual-Function Monitoring — tracks amperage and battery thermal conditions in one compact, easy-to-read gauge
• Expanded Amp Range — monitors current from -200 to 1200A for detailed power usage visibility
• Warning Light — activates above 104°F (40°C) for a clear high-temperature battery alert
• Compact Dual-Gauge Design — maximizes dashboard space while keeping critical EV data in view
• Stepper Motor Precision — smooth, accurate pointer movement
• Microprocessor-Driven — real-time accuracy
• Made in the USA — backed by a lifetime warranty

Speedhut EV Gauge Instructions (pdf)
